Product Details:
Payment & Shipping Terms:
|
| Features: | OEM Quality | Type: | Disc Geroler Motor |
|---|---|---|---|
| Series: | 110-1073-006 | Material: | Cast Iron |
| Origin: | China | Displacement: | 311cm |
| Mounting Type: | Wheel Mounting, 4 BOLT | ||
| Highlight: | 311.5cc Hydraulic Geroler Disc Valve Motor,EATON Hydraulic Geroler Disc Valve Motor,CHAR-LYNN Hydraulic Geroler Disc Valve Motor |
||
Quick review:
| Mounting flange | Wheel, 4 Bolt; 127.00 [5.000] Pilot Dia. .500-13 UNC-2B Threaded Holes On 147.62 [5.812] Dia. Bolt Circle |
| Drive shaft | Taper |
| Displacement (cm³/r) | 311.8cc |
| Direction of rotation | Clockwise and counterclockwise |
| Inlet port | 1.0625-12 UN-2B SAE O-Ring Ports - Staggered Ports |
| Outlet port | 1.0625-12 UN-2B SAE O-Ring Ports - Staggered Ports |
| Positition oil ports | Side |
| Options | No |
| Drain port | .4375-20 UNF-2B SAE O-Ring Port With Check Valve |
| Seal material | NBR |
| Shaft seal type | Standard |
| Type | Geroler Disc Valve |
| Code | 110-1073-006 |
| Application | Mowing, Snow Removal, Sprayer, Trencher, Wood Products |
other types
| 110 | 130 | 160 | 205 | 245 | 310 | 395 | 495 | 625 |
| 4-110AAA-F | 4-130AAA-F | 4-160AAA-F | 4-200AAA-F | 4-250AAA-F | 4-310AAA-F | 4-390AAA-F | 4-490AAA-F | 4-630AAA-F |
| 4-130ABA-F | 4-160ABA-F | 4-160ABA-F | 4-200ABA-F | 4-250ABA-F | 4-310ABA-F | 4-390ABA-F | 4-490ABA-F | 4-630ABA-F |
| 4-110ACA-F | 4-130ACA-F | 4-160ACA-F | 4-200ACA-F | 4-250ACA-F | 4-310ACA-F | 4-390ACA-F |
Low speed high torque hydraulic motors play an irreplaceable role in industry, agriculture and other fields due to their unique performance advantages and wide range of applications. With the continuous progress and innovation of technology, the performance of low speed high torque hydraulic motor will be further optimized and the application fields will be further broadened. Hanjiu company produces and sells high quality Low speed high torque hydraulic motor, if you want to know more about the professional knowledge, you can go to the official website of Hanjiu company to browse, Hanjiu company produces hydraulic pumps and spare parts. The products are sold all over the world and have gained good reputation and feedback. At present, we have agents in more than ten countries and regions around the world.
