OMT315 Hydraulic Motor 151B2053--BMT-315-4-M-D For Jaw Crusher Spare Parts

Large Image : OMT315 Hydraulic Motor 151B2053--BMT-315-4-M-D For Jaw Crusher Spare Parts

Product Details:

Place of Origin:	China
Brand Name:	HANJIU
Certification:	ISO9001:2015
Model Number:	BMT315

Payment & Shipping Terms:

Minimum Order Quantity:	20 Sets
Price:	Negotiable
Packaging Details:	Carton Packing, and finally with pallet or wooden box
Payment Terms:	L/C, T/T, Western Union, Paypal
Supply Ability:	100,000 Sets per year

Contact Now

Detailed Product Description

Categories:	Hydraulic Heavy Motor	Name:	OMT315
Max.output:	Cont.31.2kw/int.35kw	Max Torque:	Cont.1080N.m/int.1260N.m
Flange:	Square Flange	Shaft:	Straight Key Shaft
Highlight:	151B2053 Hydraulic Motor , jaw crusher spare parts Hydraulic Motor , OMT315 Hydraulic Motor

OMT315 Hydraulic Motor 151B2053--BMT-315-4-M-D for jaw crusher spare parts

Details

type code 151B2053=Hanjiu code BMT-315-4-M-D Which is widely used on jaw crusher

Output volume (cc/rev): 326.3
Shaft: φ40 straight key shaft, parallel key 12x8x70
max r.p.m.: 380
Torque max. (Nm): 950/1140
Power max. (kW): 30
Pressure difference (bar): 180
Inlet pressure (bar): 280
Volume flow max. (l/min): 125
Engine version: with non-return valves
Connection: G 3/4
Leakage oil connection: G 1/4

Main Specifications:

Type		BMT 160	BMT 200	BMT 230	BMT 250	BMT 315	BMT 400	BMT 500	BMT 630	BMT 800
displacement (cm3/rev. )		161.1	201.4	232.5	251.8	326.3	410.9	523.6	629.1	801.8
Max. speed (rpm)	cont.	625	625	536	500	380	305	240	196	154
Max. speed (rpm)	int.	780	750	643	600	460	365	285	233	185
Max. torque (N.m)	cont.	470	590	670	730	950	1080	1220	1318	1464
	int.	560	710	821	880	1140	1260	1370	1498	1520
	peak	669	838	958	1036	1346.3	1450.3	1643.8	1618.8	1665
Max. output (KW)	cont.	27.7	34.9	34.7	34.5	34.9	31.2	28.8	25.3	22.2
Max. output (KW)	int.	32	40	40	40	40	35	35	27.5	26.8
Max.pressure drop (MPa)	cont.	20	20	20	20	20	18	16	14	12.5
	int.	24	24	24	24	24	21	18	16	13
	peak	28	28	28	28	28	24	21	19	16
Max. flow (L/min)	rated	80	100	100	100	100	100	100	100	100
	cont.	100	125	125	125	125	125	125	125	125
	int.	125	150	150	150	150	150	150	150	150
Max. inlet pressure (Mpa)	cont.	21	21	21	21	21	21	21	21	21
	int.	25	25	25	25	25	25	25	25	25
	peak	30	30	30	30	30	30	30	30	30
Weight (kg)		19.5	20	20.4	20.5	21	22	23	24	25

OMT315 Hydraulic Motor 151B2053--BMT-315-4-M-D For Jaw Crusher Spare Parts 0

OMT315 Hydraulic Motor 151B2053--BMT-315-4-M-D For Jaw Crusher Spare Parts 2

Advantages of Orbital Hydraulic Motors

High starting torque: Ideal for heavy loads.

Smooth operation: Provides consistent output.

Compact design: Efficient use of space.

Reversible: Can operate in both directions.

Wide speed range: Can operate at low and high speeds.

Applications

Orbital hydraulic motors are used in a variety of applications, including:

Construction equipment

Agricultural machinery

Material handling equipment

Marine applications

Industrial machinery
