| Material: | Cast Iron | Model: | BMSY-100 |
|---|---|---|---|
| Fastening: | SAE Bmounting | Displacement: | 100 CM3/R |
| Shaft: | 31.75mm Key Shaft | Port: | 7/8-14UNF |
| Highlight: | SAE B flange motor hydraulic pump,31.75mm motor hydraulic pump,7/8-14unf motor hydraulic pump |
||
the details as below
hanjiu code :BMSY-100-E2B-G-EE-S2
| DISPLACEMENT | 100CC |
SERIES | OMS Series,MS Series, |
| PORT LOCATION | rear Port, Staggered |
| SHAFT TYPE | 31.75MM STRAIGHT KEY |
| DRAIN | 7/8-14UNF |
| MAXIMUM SPEED @ CONTINUOUS FLOW | 191 rpm/287rpm |
| FLOW RATE | 75l/min |
| RPM [MAX] | 287rpm |
| DUTY | Standard-Duty |
| GEROTER/GEROLER OPTIONS | Standard |
| MOUNTING TYPE | 2-Ø14.3 Rhomb-flange Ø146.05,pilot Ø101.6×9.4 |
| PORT SIZE | 7/8-14UNF |
| MOTOR TYPE | Disc Valve |
The working principle of a hydraulic motor is based on Pascal's principle, which states that the pressure on a liquid inside a closed container is equal in all directions. When the liquid enters the cavity of the hydraulic motor, it is subjected to pressure that pushes the rotor to rotate. By varying the flow and pressure of the liquid, the speed and torque of the hydraulic motor can be controlled.
Hydraulic motors have many advantages, such as compact structure, small size, light weight, reliable work, etc. It can work in harsh environments, is insensitive to oil contamination, and is easy to achieve stepless speed change and forward and reverse control. Therefore, hydraulic motors are widely used in various mechanical equipment, such as injection molding machinery, ships, construction machinery, construction machinery, etc.
It should be noted that the hydraulic motor needs regular maintenance and maintenance during use to ensure that it works properly. At the same time, when choosing a hydraulic motor, it is necessary to choose according to the actual working requirements and conditions to ensure that it can meet the requirements of use.
