China Hydraulic Motor Manufacturer Bottom Port Motor BMR Series Replaces OMR MR Series

Large Image : China Hydraulic Motor Manufacturer Bottom Port Motor BMR Series Replaces OMR MR Series

Product Details:

Place of Origin:	China
Brand Name:	HANJIU
Certification:	CE, ISO9001
Model Number:	BMR-160-H5-A-S

Payment & Shipping Terms:

Minimum Order Quantity:	100 Pieces
Price:	50 usd/pc
Packaging Details:	box, pallet, carton
Delivery Time:	0 - 35 work days
Payment Terms:	T/T
Supply Ability:	10000 pieces per month

Contact Now

Detailed Product Description

Product:

Hydraulic Motor

Size:

160 Ml/r

Port:

Rear Port

100 Pcs

Highlight:

BMR Series Hydraulic Motor

China Manufacturer Hydraulic Motor

Replaces OMR MR Series Hydraulic Motor

Welcome!

Hanjiu manufactures a variety of hydraulic motors to suit a variety of applications and equipment
low seed high torque motors 8 - 980 cm3,
2 bolt, 4 bolt, 6 bolt, standard, wheel mouting,
standard, free running, big radial force, speed sensor, brake function

Bottom Port Motor BMR Series Replaces OMR MR Series

Quick review: BMR-160-H5-A-S

displacement	160 ml/r
flange	4-M10 wheel mount
ports	7/8-14 O-ring
output shaft	25mm
rotation	CCW
paint	black

China Hydraulic Motor Manufacturer Bottom Port Motor BMR Series Replaces OMR MR Series 0

Specification:

Main Specifications:

Technical data for BMR with 25 and 1 in and 1 in splined and 28.56 tapered shaft:

Type		BMR BMRS 36	BMR BMRS 50	BMR BMRS 80	BMR BMRS 100	BMR BMRS 125	BMR BMRS 160	BMR BMRS 200	BMR BMRS 250	BMR BMRS 315	BMR BMRS 375
Geometric displacement (cm3 /rev.)		36	51.7	81.5	102	127.2	157.2	194.5	253.3	317.5	381.4
Max. speed (rpm)	cont.	1085	960	750	600	475	378	310	240	190	155
Max. speed (rpm)	int.	1220	1150	940	750	600	475	385	300	240	190
Max. torque (N·m)	cont.	72	100	195	240	300	360	360	390	390	365
	int.	83	126	220	280	340	430	440	490	535	495
	peak	105	165	270	320	370	460	560	640	650	680
Max. output (kW)	cont.	8.5	9.5	12.5	13	12.5	12.5	10	7	6	5
Max. output (kW)	int.	9.8	11.2	15	15	14.5	14	13	9.5	9	8
Max. pressure drop (MPa)	cont.	14	14	17.5	17.5	17.5	16.5	13	11	9	7
	int.	16.5	17.5	20	20	20	20	17.5	15	13	10
	peak	22.5	22.5	22.5	22.5	22.5	22.5	22.5	20	17.5	15
Max. flow (L/min)	cont.	40	50	60	60	60	60	60	60	60	60
Max. flow (L/min)	int.	45	60	75	75	75	75	75	75	75	75
Weight (kg)		6.5	6.7	6.9	7	7.3	7.6	8	8.5	9	9.5

Technical data for BMR with 31.75 and 32 shaft:

Type		BMR BMRS 36	BMR BMRS 50	BMR BMRS 80	BMR BMRS 100	BMR BMRS 125	BMR BMRS 160	BMR BMRS 200	BMR BMRS 250	BMR BMRS 315	BMR BMRS 375
Geometric displacement (cm3 /rev.)		36	51.7	81.5	102	127.2	157.2	194.5	253.3	317.5	381.4
Max. speed (rpm)	cont.	1250	960	750	600	475	378	310	240	190	155
Max. speed (rpm)	int.	1520	1150	940	750	600	475	385	300	240	190
Max. torque (N·m)	cont.	72	100	195	240	300	380	450	540	550	580
	int.	83	126	220	280	340	430	500	610	690	690
	peak	105	165	270	320	370	460	560	710	840	830
Max. output (kW)	cont.	8.5	9.5	12.5	13	12.5	12.5	11	10	9	7.5
Max. output (kW)	int.	9.8	11.2	15	15	14.5	14	13	12	10	9
Max. pressure drop (MPa)	cont.	14	14	17.5	17.5	17.5	17.5	17.5	17.5	13.5	11.5
	int.	16.5	17.5	20	20	20	20	20	20	17.5	15
	peak	22.5	22.5	22.5	22.5	22.5	22.5	22.5	22.5	21	17.5
Max. flow (L/min)	cont.	45	50	60	60	60	60	60	60	60	60
Max. flow (L/min)	int.	55	60	75	75	75	75	75	75	75	75
Weight (kg)		6.5	6.7	6.9	7	7.3	7.6	8	8.5	9	9.5

* Continuous pressure:Max.value of operating motor continuously.
* Intermittent pressure:Max.value of operating motor in 6 seconds per minute .
* Peak pressure:Max.value of operating motor in 0.6 second per minute.

China Hydraulic Motor Manufacturer Bottom Port Motor BMR Series Replaces OMR MR Series 2

China Hydraulic Motor Manufacturer Bottom Port Motor BMR Series Replaces OMR MR Series 3

More BMR series hydraulic motors available:

About the manufacturer Hanjiu:

HANJIU is a hydraulic motor manufacturing company from China. More than a thousand types of hydraulic motors are widely used in automated hydraulic systems in engineering, construction, agriculture, forestry, fishery, ports, docks, mines, etc. For example, mixing machine manufacturer in Italy, sweeping machine manufacturer in UK, construction equipment manufacturers in Germany, tractor manufacturers in Turkey, mining rig manufacturers in North America, and dealers from Danfoos, Eaton, Parker, and White are all good partners for us. If you are an equipment manufacturer or hydraulic distributor, please contact us to discuss your needs and learn how we can better realize your needs.

China Hydraulic Motor Manufacturer Bottom Port Motor BMR Series Replaces OMR MR Series 5
