Product Details:
Payment & Shipping Terms:
|
| Product: | High Torque Hydraulic Motor | Model Number: | BME2-50-H4S-H |
|---|---|---|---|
| Displacement: | 50 Ml/r | Speed: | 667-842 Rpm |
| Torque: | 126-176 Nm | Output: | 8.3-13.9 Kw |
| Pressure Drop: | 14 - 19 MPa | Flange: | Square Mount |
| Shaft: | 25.4mm Key Shaft With Hole | Rotation: | CCW |
| Highlight: | tb Parker Gerotor Motors,te Parker Gerotor Motors,TC Parker Gerotor Motors replacement |
||
Parker Gerotor Motors TE, TB, TC Series replacement, 1 inch key shaft, square flange, high toque motor
Quick review:
Model number: BME2-50-H4S-H
Displacement, 50 ml/r
Speed, 667-842 rpm
Torque, 126-176 Nm
Output, 8.3-13.9 Kw
Pressure Drop, 14 - 20 MPa
Flange, square mount
Shaft, 25.4mm key shaft with hole
Rotation, CCW
Features, suit Parker TB, TC, TE
Here is it's technical details:
| Type | BME2 | BME2 | BME2 | BME2 | BME2 | BME2 | BME2 | BME2 | BME2 | BME2 | BME2 | |
| 65 | 80 | 100 | 125 | 160 | 200 | 230 | 250 | 295 | 315 | 375 | ||
| Geometric displacement (cm3 /rev.) | 66.8 | 81.3 | 101.6 | 127 | 157.2 | 193.6 | 226 | 257 | 287.8 | 314.5 | 370 | |
| Max. speed (rpm) | cont. | 667 | 543 | 439 | 350 | 283 | 229 | 247 | 216 | 196 | 178 | 152 |
| int. | 842 | 689 | 553 | 441 | 355 | 289 | 328 | 287 | 254 | 235 | 199 | |
| Max. torque (N•m) | cont. | 126 | 157 | 191 | 245 | 307 | 382 | 378 | 381 | 393 | 448 | 439 |
| int. | 176 | 215 | 268 | 335 | 422 | 520 | 528 | 543 | 547 | 587 | 613 | |
| Max. output (kW) | cont. | 8.3 | 8.8 | 7.9 | 8.9 | 8.9 | 9 | 9.9 | 9.3 | 8.7 | 8 | 7.6 |
| int. | 13.9 | 14.4 | 13.5 | 14.1 | 15.6 | 15.7 | 17.9 | 16.5 | 15.6 | 14.3 | 14 | |
| Max. pressure drop (MPa) | cont. | 14 | 14 | 14 | 14 | 14 | 14 | 12 | 11 | 10 | 10 | 9 |
| int. | 19 | 19 | 19 | 19 | 19 | 19 | 165 | 15.5 | 14.5 | 13.5 | 12.5 | |
| peak | 20 | 20 | 20 | 20 | 20 | 20 | 18 | 18 | 17 | 16 | 16 | |
| Max. flow (L/min) | cont. | 45 | 45 | 45 | 45 | 45 | 45 | 57 | 57 | 57 | 57 | 57 |
| int. | 57 | 57 | 57 | 57 | 57 | 57 | 75 | 75 | 75 | 75 | 75 | |
BME2 series motor is a reliable and efficient hydraulic motor that offers numerous benefits to industries. Its high efficiency, robust construction, compact size, and wide speed range make it a preferred choice for many applications. With its ability to increase productivity, save costs, and provide reliable performance, Motor BME2 proves to be an excellent investment for businesses seeking optimal hydraulic solutions.
HANJIU hydraulic motor expert, rich specifications, rapid manufacturing, reasonable price, perfect service, looking forward to your consultation
