BMS 200 Hydraulic Motor 32mm 1/2BSPP Replace 151F0504 Danfoss OMS200

Large Image : BMS 200 Hydraulic Motor 32mm 1/2BSPP Replace 151F0504 Danfoss OMS200

Product Details:

Place of Origin:	China
Brand Name:	HANJIU
Certification:	CE, ISO9001
Model Number:	BMSY-200

Payment & Shipping Terms:

Minimum Order Quantity:	100 Pieces
Price:	88 usd/pc
Packaging Details:	Box, carton, pallet
Delivery Time:	45 - 55 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, Payple
Supply Ability:	70000 pieces per year

Contact Now

Detailed Product Description

Product:	Hydraulic Motor	Model No.:	BMSY-200
Displacement:	200cc	Flange:	4 Bolt
Shaft:	32mm	Port:	G 1/2
Rotation:	Standard	Color:	Black
Manufacturer:	Hanjiu	Brand:	Hanjiu
Highlight:	200cc Hydraulic Motor , BMS 200cc Hydraulic Motor , OMS200 Danfoss Hydraulic Motor

OMS 200 Hydraulic Motor 32mm 1/2BSPP replace 151F0504 Danfoss OMS200

Quick review:

Model No.	BMS 200
Shaft	32mm Cylindrical
Geometric displacement	200 cm³
Max. speed continuous.	375 rpm
Max. speed intermittent.	450 rpm
Max. torque continuous.	586 Nm
Max. torque intermittent	705 Nm
Max. output continuous.	18.1 kw
Max. output intermittent.	24.0 kw
Max. pressure continuous	210 bar
Max. pressure intermittent.	250 bar
Max. pressure peak	270 bar

Hanjiu BMS 200 apply to Skid Steer Attachments

Also BMS series with more mounting and shaft apply to Swing Motor, Brush Cutters & Mowers, Harvesting Equipment, Directional Boring any place pressure relief protection is optimal for system or motor performance and life, Turf equipment and more.

Specification:

Main Specifications:

Type		BMS BMSE 80	BMS BMSE 100	BMS BMSE 125	BMS BMSE 160	BMS BMSE 200	BMS BMSE 250	BMS BMSE 315	BMS BMSE 375
Geometric displacement (cm3 /rev.)		80.6	100.8	125	157.2	200	252	314.5	370
Max. speed (rpm)	cont.	800	748	600	470	375	300	240	200
Max. speed (rpm)	int.	988	900	720	560	450	360	280	240
Max. torque (N·m)	cont.	190	240	310	316	400	450	560	536
	int.	240	300	370	430	466	540	658	645
	peak	260	320	400	472	650	690	740	751
Max. output (kW)	cont.	15.9	18.8	19.5	15.6	15.7	14.1	14.1	11.8
Max. output (kW)	int.	20.1	23.5	23.2	21.2	18.3	17	18.9	17
Max. pressure drop (MPa)	cont.	17.5	17.5	17.5	15	14	12.5	12	10
	int.	21	21	21	21	16	16	14	12
	peak	22.5	22.5	22.5	22.5	22.5	20	18.5	14
Max. flow (L/min)	cont.	65	75	75	75	75	75	75	75
Max. flow (L/min)	int.	80	90	90	90	90	90	90	90
Max. inlet pressure (MPa)	cont.	25	25	25	25	25	25	25	25
Max. inlet pressure (MPa)	int.	30	30	30	30	30	30	30	30
Weight (kg)		9.8	10	10.3	10.7	11.1	11.6	12.3	12.6

* Continuous pressure :Max. value of operating motor continuously.
* Intermittent pressure :Max. value of operating motor in 6 seconds per minute.
* Peak pressure:Max. value of operating motor in 0.6 second per minute.

Dimentions:

BMS 200 Hydraulic Motor 32mm 1/2BSPP Replace 151F0504 Danfoss OMS200 0

BMS 200 Hydraulic Motor 32mm 1/2BSPP Replace 151F0504 Danfoss OMS200 1

More hydraulic motors available:

BMS 200 Hydraulic Motor 32mm 1/2BSPP Replace 151F0504 Danfoss OMS200 2

About Hanjiu:

Hanjiu technology is the biggest hydraulic motors, orbit motors, low speed high torque motors, torquemotors manufacturer in China, we have the most completely range of them, matching Danfoss/ M+S/ Charlynn/ White/ Parker... with fast leading time, excellent price and best service. Our aim is to make your hydraulic system is easy and affordable!
