Product Details:
Payment & Shipping Terms:
|
| Item: | Orbital Motor | OEM #: | BMER-2 |
|---|---|---|---|
| Manufacturer: | Hanjiu | Displacement: | 250ml/r |
| Mounting Flange: | Wheel Mounting Flange | Shaft Type: | 31.75mm Key Shaft |
| Highlight: | BMER-2 Wheel Hydraulic Motors,BMER-2 High Torque Hydraulic Motor,Combi Sweeper Wheel Hydraulic Motors |
||
Quick review: This is Parker compatible motor with same form, fit and function Apply to hydraulic bucket brush combi sweeper Here is main specifications: Standard rotation BMER 125 BMER 160 BMER 200 BMER 230 BMER 250 BMER 300 BMER 350 BMER 375 BMER 475 BMER 540 BMER 750 Geometric displacement (cm3 /rev.) About Hanjiu: Hanjiu Technology Co., Ltd. manufactures low-speed and high-torque hydraulic orbital motors. Importers, distributors and users use it's low-speed and high-torque hydraulic orbital motors as an affordable alternative to Torqmotor Parker (also known as Torqmotor Ross). The market feedback is positive. good. At present, the company have cooperated with Parker torqmotor dealers ( Ross Torqmotor dealers) and users from the United States, Canada, Australia, South Africa, UAE, Germany, Turkey, Mexico, Brazil, Chile and more regions, and provided them with numerous of professional hydraulic orbital motors, Significantly save costs while greatly increasing profit margins. At present, the low-speed and high-torque hydraulic orbital motor that we have independently developed can be used interchangeably with the following models of torqmotor parker in form, fit, and function: torqmotor parker tg series torqmotor parker tf series torqmotor parker te series torqmotor parker tb series torqmotor parker th series torqmotor parker tj series high torque motor TG series wheel motors for hydraulic bucket brush combi sweeper
Series:
Parker TG Motor
Shaft:
31.75mm key shaft
Rotation:
Displacement (cm3/rev):
0240
Mounting:
Wheel mounting
Geometric Displacement:
240cm3/rev (214.5in3/rev)
Maximum Oil Flow (continuous / intermittent):
75 lpm (20 gpm) / 90 lpm (24 gpm)
Max. Differential Pressure (continuous / intermittent):
205 bar (3000 PSI) / 240 bar (3500 PSI)
Maximum Supply Pressure:
276 bar (4000 PSI)
Maximum Torque - Continuous / Intermittent:
990 Nm (8900lb-in) / 1140Nm (10250 lb-in)
Maximum Output(continuous / intermittent)
16.5 KW /19kw
Main Specifications:
Type
118
156
196
228
257
296
345
371
462
540
745
Max. speed (rpm)
cont.
360
375
330
290
290
250
220
200
160
140
100
int.
490
470
425
365
350
315
270
240
195
170
120
Max. torque (N*m)
cont.
325
450
530
625
700
810
905
990
1085
980
1050
int.
380
525
600
710
790
930
1035
1140
1180
1240
1180
peak
450
590
750
870
980
1120
1285
1360
1260
1380
1370
Max. output (kW)
cont.
12.0
15
15.5
16.0
17.5
18.0
17.5
16.5
14.5
11.5
8.0
int.
14.0
17.5
18.0
19.0
20.0
21.0
20.0
19.0
16.5
15.0
10.0
Max. pressure drop (MPa)
cont.
20.5
20.5
20.5
20.5
20.5
20.5
20.5
20.5
17.5
14
10.5
int.
24
24
24
24
24
24
24
24
19
17.5
12
peak
27.6
27.6
27.6
27.6
27.6
27.6
27.6
27.6
20.5
20.5
14
Max. flow (L/min)
cont.
45
60
70
70
75
80
80
75
75
75
75
int.
60
75
85
85
90
95
95
90
90
90
90
