Product Details:
Payment & Shipping Terms:
|
| Item: | Orbit Hydraulic Motor | Model: | 104-3358-006 |
|---|---|---|---|
| Fastening: | 2 Bolt | Displacement: | 393.8 CM3/R |
| Shaft: | 14 TOOTH | Port: | Staggered Ports |
| Highlight: | 104-3358-006 disc valve hydraulic motor,char lynn disc valve hydraulic motor,191 rpm disc valve hydraulic motor |
||
104-3358-006 CHARLYN 2000 SERIES, 2 BOLT, 393.8 CM3/R, 14 TOOTH
Quick view:
Hanjiu offers Eaton Char-lynn 2000 series high-end compatible motors with the same build and performance, fast delivery, and a more reasonable price. Below are the details
Specification:
104-3358-006
M02240AC04AA0100010001900ATAAF
| Item | Gearmotor |
| Flow Rate | 75 LQ |
| Height | 6.96" |
| Length | 11.66" |
| Material | Cast Iron |
| Mounting Type | Standard, 2 Bolts |
| Port Type | 0.875-14 UNF |
| Shaft Type | Spline |
| Speed | 191 RPM |
| Torque | 775 Nm |
| Width | 5.16" |
More 2000 series EATON / CHAR-LYNN hydraulic motors available:
| 104-1226-006 | 104-1199-006 | 104-1564-006 |
| 104-1227-006 | 104-1252-006 | 104-1605-006 |
| 104-1228-006 | 104-1382-006 | 104-1608-006 |
| 104-3358-006 | 104-1390-006 | 104-1611-006 |
| 104-1007-006 | 104-1406-006 | 104-1702-006 |
| 104-1014-006 | 104-1467-006 | 104-1716-006 |
| 104-1021-006 | 104-1522-006 | 104-1720-006 |
| 104-1028-006 | 104-1547-006 | 104-1759-006 |
| 104-1035-006 | 104-1554-006 | 104-1792-006 |
| 104-1043-006 | 104-1982-006 | 104-1854-006 |
| 104-1067-006 | 104-1989-006 | 104-1876-006 |
| 104-1085-006 | 104-1991-006 | 104-1877-006 |
More series EATON / CHAR-LYNN hydraulic motor available
| J (129-) | 2000 (104-, 105-, 106-, 193-) |
| H (101-) | 4000 (109-, 110-, 111-) |
| S (103-) | 6000 (112-, 113-, 114-) |
| T (158-) | 10000 ( 119-) |
| W (162-) |
About Hanjiu:
Hanjiu Technology specialized in a large variety of hydraulic components to suit a range of brands and applications. We serve OEM project as well as aftermarket. If your current business is facing difficulties, if your supply chain, product, quality, price, delivery, after-sales, etc. are facing problems, or you are looking for a more reliable partner who can help you solve the above problems, do not hesitate to get in touch with us.
We will do our best to meet your requirements at the best possible price and lead time.
