Product Details:
Payment & Shipping Terms:
|
| Model No.: | HSSD8 | Warranty: | 1year |
|---|---|---|---|
| Spool: | 1, 2, 3, 4, 5, 6, ... | Flow: | 80lt, |
| Spool Function: | O/Y/A | Control Type: | Joystick Valves |
| Highlight: | wood grabber directional control valve,wood loader hydraulic joystick valves,electric control hydraulic joystick valves |
||
Product details:
| flow rate |
80lpm |
| pressure | 160-315bar |
| control way |
manual,electric,joystick control |
| spring side control options |
spring and detent control |
| testing | 100%tested before package |
| testing items |
internal leakge, outside leakage, relief valve working pressure,check valve, spool functions |
| internatal leakage | less than 5ml/min |
| warranty | 12months |
The technical features, flow rate and pressure limit make the HSSD8 valves ideal for different applications.
Applications :
Cranes, Telescopic boom fork lifts, Back-hoe Excavators and Compactors, vertical and horizontal drilling rigs,
Front-loaders, forestry machines, skid steer loaders and mini dumpers, cranes, wheel loaders
Compact, lightweight design
Can be fitted with integrated proportional electrohydraulic control
1.The hydraulic control valve produced by Hanjiu Technology Co., Ltd. has a long service life. Hanjiu Technology produces at least 500,000 sets of related products every year. All products will undergo strict quality inspection before leaving the factory to ensure the quality of these products to the greatest extent. And industrial production makes the quality of these products all the same, there is no inferior product
2. The monoblock hydraulic control valve produced by Hanjiu Technology Co., Ltd. has a very high cost performance. Hanjiu Technology always insists on giving the maximum profit to the dealers, so as to ensure that customers can buy the best products at the lowest price.
3. The goal of Hanjiu Technology Co., Ltd. is to serve the world and do long-term business, so they pay special attention to after-sales service, always put customer needs first, sincerely consider and plan for customers, and encounter any problems during use You can consult customer service
