Product Details:
Payment & Shipping Terms:
|
| Item: | Hydraulic Geroler Disc Valve Motor | OEM #: | 104-1027-006, |
|---|---|---|---|
| Manufacturer: | Hanjiu | Displacement: | 244.3ml/r |
| Mounting Flange: | 2-hole Wheel Flange | Shaft Type: | Straight |
| Highlight: | 104-1027-006,104-1027-006 orbit hydraulic motor,2000 series orbit hydraulic motor |
||
OVERVIEW * Three-zone design for longer life and true bi-directionality * Bearings that meet the highest standards of the industry * Options to optimize performance in every application * Integrated crossover relief valve option * Two-bolt flange: SAE A with 3-1/4" pilot diameter * drain: 7/16"-20 UNF-2B O-ring port size 4 SPECIFICATIONS 104-1027-006, Hydraulic Geroler Disc Valve Motor 2000 series Standard, 244.3 cm³/r Max Geometric Displacement
This is a 104-1027-006 replacement motor.
Series
2000 - Standard
Displacement
14.91 in³/r
Mounting Type
2-Bolt Flange - 3.25 in Pilot - SAE A
Shaft Type
Straight
Maximum Operating Temperature
180 °F
Output Shaft Size
1-1/4 in Straight - Straight Key
Seal Type
Standard
Drain Connection Size
.4375-20 Unf-2b O-ring Port Size -4
